Standard Features

·Effective volume:1500L, total volume:1875L

·Net Dimension=φ1360*2150mm, double-layer with insulation

·Temperature probe: PT-100

·Level tube

·Insulated conical top and sloped bottom

·Glycol water inlet and outlet

·With 5m3/h glycol water pump

·Inner-jacket(SUS304)thickness: 3mm,pickling and passivating treated;

·External-Jacket(SUS304) thickness: 2mm, Hairline polishing;

·Oval head thickness: 3mm.

·Insulation layer: PU-thickness=80mm.

·100% high accuracy TIGwelding.

·4pcs completely SUS304 heavy duty legs with adjustable bolt

Optional features:

·Size from 300L to 6000L

·The height is adjustable

·The dimension is adjustable

·The manhole is sight glass or atmospheric manhole
